Deep Foundation Solutions

Reliable Foundations for Demanding Projects

PDS Piling & Foundation Contracting LLC delivers professional bored piling services for residential, commercial, industrial and infrastructure developments across the UAE and India.

Bored piles transfer structural loads through weaker near-surface ground into deeper, more competent soil or rock layers. Our team combines experienced engineering, suitable drilling methods and controlled site execution to deliver dependable deep foundation systems for challenging project conditions.

From initial planning and drilling to reinforcement installation, concreting and quality documentation, every stage is managed with a strong focus on safety, accuracy and long-term structural performance

Explore Our Projects
Why Bored Piles?

Strength, Flexibility and Controlled Installation

Bored piling is widely used where high load capacity, larger pile diameters or deeper foundation levels are required.

High Load Capacity

Suitable for supporting heavy structures and demanding foundation loads.

Flexible Dimensions

Pile diameter and depth can be selected to suit the project design and ground conditions.

Reduced Vibration

Drilled installation can be suitable for sites near existing buildings and sensitive surroundings.

Complex Ground Conditions

Adaptable drilling and casing methods can be used to address varying soil profiles and groundwater conditions.

Typical Applications

Bored Piling for Diverse Construction Sectors

Our bored piling solutions can support a wide range of developments, from complex urban construction to large-scale infrastructure. The final pile system is selected according to structural loads, geotechnical information, access constraints and project requirements.

  • High-rise and multi-storey buildings
  • Commercial and mixed-use developments
  • Industrial facilities and warehouses
  • Bridges and infrastructure structures
  • Hotels, hospitals and institutional buildings
  • Heavy equipment and specialised foundations
  • Projects with deep weak soil layers
  • Sites requiring controlled vibration levels
Our Execution Process

From Site Preparation to Completed Pile

The exact construction sequence depends on the approved design, ground conditions and project specifications.

01

Planning and Setting Out

We review the approved drawings, project requirements and available geotechnical information before establishing pile locations and work zones.

02

Drilling Preparation

The work platform, rig position and necessary temporary support arrangements are prepared for controlled drilling.

03

Bore Formation

Drilling proceeds to the required depth using suitable tools, casing or bore-support methods where required.

04

Bore Cleaning and Inspection

The completed bore is cleaned and checked in accordance with the approved method statement and project quality requirements.

05

Reinforcement Installation

The fabricated reinforcement cage is carefully lifted and positioned to maintain alignment and the specified concrete cover.

06

Concrete Placement

Concrete is placed using the approved method, with records maintained for quality control, traceability and project documentation.

Engineering, Safety and Quality

Controlled Execution You Can Depend On

Bored piling requires disciplined planning and careful coordination between engineering, plant, site and quality teams. PDS Piling follows project-specific method statements, inspection procedures and safety requirements throughout execution.

Our teams monitor critical stages such as pile positioning, drilling depth, bore stability, reinforcement placement and concrete delivery. Project records are maintained to support transparent communication, inspection and handover.

Project-Specific Planning

Methods aligned with design and site conditions

Experienced Site Teams

Coordinated engineering and field execution

Documented Quality

Inspection and execution records for traceability

Planning a Bored Piling
Project in the UAE?

Speak with the PDS Piling team about your project location,
foundation requirements, programme and site conditions.
Discuss with us
Frequently Asked Questions

Bored Piling in the UAE

What is a bored pile?

A bored pile is a cast-in-place deep foundation element formed by drilling a cylindrical bore into the ground, installing reinforcement where required and filling the bore with concrete.

Where are bored piles commonly used?

They are commonly used for high-rise buildings, commercial developments, industrial structures, bridges and projects that require deep, high-capacity foundations.

How is the diameter and depth of a bored pile selected?

The dimensions are determined by the foundation design, structural loads, soil profile, groundwater conditions and project-specific engineering requirements.

Can bored piling be used near existing buildings?

Bored piling can be suitable for constrained urban sites because it is a drilled method with comparatively controlled vibration. The final method must still be reviewed against the actual site conditions and nearby structures.

What quality checks are carried out during bored piling?

Checks may include pile position, bore depth, bore condition, reinforcement details, concrete records and any testing specified by the consultant or project requirements.

Does PDS Piling provide bored piling services in Dubai and Abu Dhabi?

Yes. PDS Piling serves projects in Dubai, Abu Dhabi and other regions across the UAE, subject to project scope, mobilisation and site requirements.

Can PDS Piling support both piling and associated foundation works?

PDS Piling provides a wider range of services including bored piles, CFA piles, micropiles, shoring, soldier piles, drilling, excavation, anchors and foundation engineering.
